Power transformers are protected using a combination of electrical, mechanical, and thermal relays to detect faults and prevent damage.

Key Protection Relays and Measures

1. Differential Protection (87): Differential relays are the most sensitive protection for internal transformer faults. They compare currents entering and leaving the transformer windings. Any imbalance indicates an internal fault, triggering the relay to trip circuit breakers. Proper operation requires matched current transformers (CTs) on all windings, with carefully selected CT ratios and accuracy to ensure reliable detection of winding faults . 2. Overcurrent Protection: Overcurrent relays protect transformers against overloads and external short-circuit faults. They are typically used as backup protection and are coordinated with upstream and downstream devices to prevent unnecessary tripping . 3. Restricted Earth Fault (REF/64) Protection: REF relays provide sensitive earth fault protection within the transformer zone. They detect ground faults that may not be visible to standard overcurrent relays, offering fast and selective isolation of earth faults . 4. Buchholz Relay (Gas Detection): A Buchholz relay is installed between the transformer tank and conservator. It detects gas accumulation caused by internal arcing or insulation failure. Alarms indicate minor faults, while tripping occurs for severe internal faults. Gas analysis can differentiate between internal faults (combustible gas) and external leaks (air), . 5. Thermal and Overheating Protection: Thermal relays monitor winding and oil temperatures to prevent insulation damage from prolonged overloads. Fiber-optic sensors or thermal relays can trigger alarms or cooling systems to maintain safe operating temperatures . 6. Over-Fluxing Protection (24): Protects the transformer core from excessive magnetic flux density, which can cause overheating and insulation stress . 7. Pressure Relief and Sudden Pressure Relays: These relays detect abnormal pressure rises inside the transformer tank due to severe internal faults, preventing tank rupture and catastrophic failure . 8. Overvoltage and Fire Protection: Transformers are also protected against external overvoltages from lightning or switching operations. Indoor installations may use less-flammable insulating fluids, and silica gel breathers prevent moisture contamination .

Implementation Considerations

• Coordination: Protection relays are coordinated with circuit breakers to ensure selective tripping, isolating only the faulty transformer while keeping the rest of the system energized .
• Layered Protection: A combination of primary and backup relays, mechanical devices, and thermal monitoring ensures comprehensive coverage for internal faults, overloads, earth faults, and abnormal operating conditions .
• Transformer Size and Type: Smaller transformers (up to 500 kVA) may use fuses, medium voltage circuit breakers, or simple relays, while larger transformers (10 MVA and above) require differential protection and advanced relay schemes .
• Maintenance and Testing: Regular testing of CTs, relay settings, and mechanical devices is essential to maintain reliability and prevent false trips or undetected faults .

Summary

Effective transformer protection relies on differential relays, overcurrent and earth fault relays, Buchholz relays, thermal and pressure monitoring, and over-fluxing protection. These measures work together to detect internal and external faults, prevent insulation damage, and ensure safe, reliable operation of power transformers in utility and industrial networks .
